Download DLL

IS Download DLL is a "plugin" for Inno Setup that allows you to download files from the Internet during the installation process. Support HTTP, HTTPS and FTP protocols.

Primarily written to be used from Inno Setup, but can be used by any software that can call DLL's. If you have the declarations needed for VB or other languages, please send them to us to include them on this page.

isxdl_Download

Immediately downloads a file from the Internet.

Syntax:

int isxdl_Download(
	HWND	hWndParent,
	LPCWSTR	pszURL,
	LPCWSTR	pszFileName
);

Parameters:

hWndParent: Handle to parent window.
pszURL: The URL to be downloaded.
pszFileName: The name of the file on the local machine.

Return Value:

Returns 1 if all files where downloaded successfully, otherwise 0.

isxdl_AddFile

Adds a file to the internal file list.

Syntax:

void isxdl_AddFile(
	LPCWSTR	pszURL,
	LPCWSTR	pszFileName
);

Parameters:

pszURL: The URL to be downloaded.
pszFileName: The name of the file on the local machine.

Return Value:

Returns nothing.

Remarks:

To access a url with basic password protection, enter something like http://username:password@www.domain.com/path/page.html as url.

isxdl_AddFileSize

Adds a file to the internal file list, and tells how big the file is. Use this if you know the size of the file, and know that it will not change. Means that the DLL won't have to find the size, which can take some time if you have many files to download.

Syntax:

void isxdl_AddFileSize(
	LPCWSTR	pszURL,
	LPCWSTR	pszFileName,
	DWORD	dwSize
);

Parameters:

pszURL: The URL to be downloaded.
pszFileName: The name of the file on the local machine.
dwSize: The size of the file.

Return Value:

Returns nothing.

isxdl_DownloadFiles

Downloads all files added with isxdl_AddFile or isxdl_AddFileSize.

Syntax:

int isxdl_DownloadFiles(
	HWND	hWndParent
);

Parameters:

hWndParent: Handle to the parent window.

Return Value:

Returns 1 if all files where downloaded successfully, otherwise 0.

isxdl_ClearFiles

Clears the internal file list. Shouldn't be necessary since files will be removed as they are successfully downloaded.

Syntax:

void isxdl_ClearFiles();

Return Value:

Returns nothing.

isxdl_IsConnected

Tells wether the computer is connected to the Internet or not. This is kind of experimental, and very little tested.

Syntax:

int isxdl_IsConnected();

Return Value:

Returns 1 if connected to the Internet, otherwise it returns 0.

isxdl_SetOption

Adds a file to the internal file list.

Syntax:

int isxdl_SetOption(
	LPCWSTR	pszOption,
	LPCWSTR	pszValue
);

Parameters:

pszOption: The option to be modified.
pszValue: The value of the option. Note that this must always be given as a string.

Return Value:

Returns 1 if the option was set successfully. Returns 0 if the option was unknown, or the option could not be set.

Remarks:

Currently these options can be set:
Option	Value
title	The title to use for the download window.
debug	Not used. Valid values are "true" and "false".
simple	Turns on simple mode if the value is a string, turns off simple mode if the value is an empty string.
label	Text for header label.
description	Text for header description.
language	Language file to get texts from.
resume	Tell it to use resume. Default is true. (Disabled.)
smallwizardimage	The image to display if you want something other than the default.

isxdl_GetFileName

Get the real file name of a downloaded file. The URL to download ISTool is 'https://www.istool.org/getistool.aspx', and before downloading isxdl_GetFileName returns 'getistool.aspx'. After downloading, the result will be 'istool-5.0.6.1.exe'.

Syntax:

LPCWSTR GetFileName(
	LPCWSTR pszURL
);

Parameters:

pszURL: The URL to get the file name for.

Return Value:

Returns the file name if the URL was found, otherwise returns NULL.

Download Plugin

Filename	Download Sites	Downloads	Date	Description
isxdl-6.0.0.zip	GitHub Our site (Netherlands)	150	2025-04-03	Archive containing isxdl.dll with Inno Setup usage examples.
isxdl-6.0.0.zip	GitHub Our site (Netherlands)	sha256 hash: de7d039dbd1efd710fdd72fe37e1db4bafb240f4b900cbe3d1a6fd536efc0c6b

Source Code

You can get the ISxDL source code via GitHub. Latest sources obtained via GitHub may contain fixes or new features not found in the latest released version of ISxDL. However, those fixes and new features may not have yet been fully tested.

Definitions for Inno Setup Pascal Scripting

function isxdl_Download(hWnd: Integer; URL, Filename: String): Integer;
	external 'isxdl_Download@files:isxdl.dll stdcall';

procedure isxdl_AddFile(URL, Filename: String);
	external 'isxdl_AddFile@files:isxdl.dll stdcall';

procedure isxdl_AddFileSize(URL, Filename: String; Size: Cardinal);
	external 'isxdl_AddFileSize@files:isxdl.dll stdcall';

function isxdl_DownloadFiles(hWnd: Integer): Integer;
	external 'isxdl_DownloadFiles@files:isxdl.dll stdcall';

procedure isxdl_ClearFiles;
	external 'isxdl_ClearFiles@files:isxdl.dll stdcall';

function isxdl_IsConnected: Integer;
	external 'isxdl_IsConnected@files:isxdl.dll stdcall';

function isxdl_SetOption(Option, Value: String): Integer;
	external 'isxdl_SetOption@files:isxdl.dll stdcall';

function isxdl_GetFileName(URL: String): String;
	external 'isxdl_GetFileName@files:isxdl.dll stdcall';

Definitions for Visual Basic

Public Declare Function isxdl_Download Lib "isxdl.dll" _
(ByVal ihWnd As Integer, ByVal strURL As String, ByVal strFilename As String) As Integer

Public Declare Function isxdl_AddFile Lib "isxdl.dll" _
(ByVal strURL As String, ByVal strFilename As String) As Integer

Public Declare Function isxdl_AddFileSize Lib "isxdl.dll" _
(ByVal strURL As String, ByVal strFilename As String, ByVal lngSize As Long) As Integer

Public Declare Function isxdl_DownloadFiles Lib "isxdl.dll" _
(ByVal ihWnd As Integer) As Integer

Public Declare Sub isxdl_ClearFiles Lib "isxdl.dll" ()

Public Declare Function isxdl_IsConnected Lib "isxdl.dll" () As Integer

Public Declare Function isxdl_SetOption Lib "isxdl.dll" _
(ByVal strOption As String, ByVal strValue As String) As Integer

Public Declare Function isxdl_GetFileName Lib "isxdl.dll" _
(ByVal strRL As String) As String

Definitions for C++

extern "C" {
	int isxdl_Download(HWND hWndParent, LPCWSTR pszURL, LPCWSTR pszFileName);
	void isxdl_AddFile(LPCWSTR pszURL, LPCWSTR pszFileName);
	void isxdl_AddFileSize(LPCWSTR pszURL, LPCWSTR pszFileName, DWORD dwSize);
	int isxdl_DownloadFiles(HWND hWndParent);
	void isxdl_ClearFiles(void);
	int isxdl_IsConnected(void);
	int isxdl_SetOption(LPCWSTR pszOption,L PCTSTR pszValue);
	LPCWSTR isxdl_GetFileName(LPCWSTR pszURL);
};

History

Version 6.0.0 (2025-04-03, 1 year ago)

Migrate project to Unicode.
Re-creating all language files (UTF-8) + added many new languages
Added HTTPS protocol support
Updated graphics (icon and small wizard image)
Added an example of using the library
General edits and project updates

Version 5.1.0 (2009-04-07, 17 years ago)

Can use a custom wizard image.
Uses SIZE command to get size of files on ftp servers.
Disabled optimization - is it me or is msvc bugging?
Won't add identical files more than once.
Disabled resume.

Version 4.0.8

Fixed a bug in resume if the server didn't support resume.
A bug caused by aborting a download was fixed.
Numbers are formatted in the default user locale.
Fixed bug that prevented cancelling downloads for illegal addresses.
Asks for user name and password if necessary when download from ftp.
Changed some error messages.
Shows icon for system menu.
Uses MS Shell Dlg font.
If resume is disabled, incomplete files will be deleted.

Version 3.0.4.3

Can use language files.
Doesn't hide parent window in simple mode.
Bug fixes.
Supports resume for http.
Spanish translation by Lobo Lunar.
Norwegian translation.

Version 3.0.4 (2002-11-30, 23 years ago)

Doesn't get size of files in simple mode.
Bugfix in isxdl_SetOption and resetting simple mode.
Standard wizard look.
Automatically hides parent window.
Two new options: label and description.

Version 1.3.1 (2002-07-24, 23 years ago)

Minor tweaks and modifications.
Added function isxdl_GetFileName to give you the real name of the downloaded file.
Fixed overflow when calculating remaining time.
Added a little about box.
Improved handling of progress bars.
Added new option 'simple' that gives you a simple window with a custom message.

Version 1.3.0 (2002-07-14, 23 years ago)

Abort should really abort (possible memory leaks though).
Supports ftp.
Handles HTTP_STATUS_MOVED if not handled by wininet (untested).
Added function IsConnected to tell whether the computer is connected to the Internet or not (experimental?).
Requires IE4.
Added function SetOption to set options.
Supported options are: 'title', 'noftpsize', 'debug', 'resume', 'language', 'label', 'description'.
Added prefix 'isxdl_' to all functions.
Added function AddFileSize with a parameter for file size.
Means the DLL will not need to check the size itself.

Version 1.2.1

Minor tweaks.
Added method ClearFiles to clear the internal file list.

Version 1.2.0

No more divide by zero errors for files less than 1024 bytes.
Supports user name and password in the url.
Demo scripts for both ISX2 and ISX3.

Version 1.0.0

Initial release.
